Double Outlet Air System Kit - SCU12 and SCU16
Due to supply constraints our kits can only be purchased in conjunction with a Frigomar air-conditioning unit.
The kit has been designed to meet the requirements for good airflow from the specified air con units to two outlets. We have used our experience to select parts that give the best balance of performance and ease of installation.
When both outlets will be in the same cabin the grilles are identical in size. When the outlets will be in different cabins, the primary cabin (which houses the air con unit and control panel) has the larger grille and the other (secondary cabin) has the smaller grille (which can be closed).
You need to select whether it is for a single cabin or two separate cabins and the type of wood you want.
Due to supply constraints our kits can only be purchased in conjunction with a Frigomar air-conditioning unit.
The kit has been designed to meet the requirements for good airflow from the specified air con units to two outlets. We have used our experience to select parts that give the best balance of performance and ease of installation.
When both outlets will be in the same cabin the grilles are identical in size. When the outlets will be in different cabins, the primary cabin (which houses the air con unit and control panel) has the larger grille and the other (secondary cabin) has the smaller grille (which can be closed).
You need to select whether it is for a single cabin or two separate cabins and the type of wood you want.
Due to supply constraints our kits can only be purchased in conjunction with a Frigomar air-conditioning unit.
The kit has been designed to meet the requirements for good airflow from the specified air con units to two outlets. We have used our experience to select parts that give the best balance of performance and ease of installation.
When both outlets will be in the same cabin the grilles are identical in size. When the outlets will be in different cabins, the primary cabin (which houses the air con unit and control panel) has the larger grille and the other (secondary cabin) has the smaller grille (which can be closed).
You need to select whether it is for a single cabin or two separate cabins and the type of wood you want.
The kit for two outlets in one cabin contains:
14 x 10 Return Air Grille (x1)
5m of insulated ducting - 150mm (6”) diameter
5m of insulated ducting - 125mm (5”) diameter
Y duct splitter - 6” inlet, 2 x 5” outlets - with adjustable internal air diverter blade
5” flat oval duct connecting spigot (x2)
Plenum box for 10 x 4 grille (x2)
10 x 4 Air Delivery Grille (x2)
The kit for two outlets in two cabins contains:
14 x 10 Return Air Grille (x1)
5m of insulated ducting - 150mm (6”) diameter
10m of insulated ducting - 125mm (5”) diameter
Y duct splitter - 6” inlet, 2 x 5” outlets - with adjustable internal air diverter blade
5” flat oval duct connecting spigot (x2)
Plenum box for 8 x 6 grille (x1)
Plenum box for 8 x 4 grille (x1)
8 x 6 Air Delivery Grille (x1)
8 x 4 (closeable) Air Delivery Grille (x1)
Note on grille sizes:
Grille sizes stated reflect the size of hole cut into the surface. The grille has a flange which is 1/2” all round. So a 10 x 4 grille needs a hole 10” x 4” and the visible part of the grille will need a surface area of 11” x 5”. Grille sizes are refered to in inches as they are American products and this is their format.
